Automatic Rotary Premade Pouch Liquid Paste Packaging Machine

MODEL: HYRP-L

BASIC INFO

Rotary Given Type Liquid Paste packing machine Technical Description

Automatic Rotary Given Type Liquid Paste packing machine is to bag type automatic packaging machine and liquid, paste filling machine and become mainly applicable to juice, tomato paste, sauce, chilli sauce, hand-washing liquid, detergent and other liquid, paste body material automatic measuring packing.

Main Features

Easy to operate, adopt advanced PLC, mate with touch screen and electric control system, the man-machine interface is friendly.
Automatic checking: no pouch or pouch open error, no fill, no seal. The bag can be used again, avoid wasting packing materials and raw materials.
Safty decice: Machine stop at abnormal air pressure, heater disconnetion alarm
The width of the bags could be adjusted by electrical motor. Press the control-button could adjust the with of all clips, easily operate, and raw materials.
The part where touch to the material is made of stainless steel.

Optional Accessories

Liquid filler
Sauce filler
Insulation storage tank
Mixer
Check weigher
Metal detector
Output conveyor
Open bag bottom device
Open zipper device
Close zipper device

Main Technical Data

Model	HYRP6-200L	HYRP8-200L
Bag types	Flat pouch, three sides sealing, four sides sealing, zipper pouch, Stand up pouch, etc
Bag material	complex film, PP, PE etc
Bag size	W:100-210mm L:150-300mm	W:100-210mm L:150-300mm
Weight range	5-1500g	5-1500g
Packing speed	20-50 bags/min Depends on material and packing amount
Air consumption	0.3m3/min
Packing accuracy	≤±1%
Power supply	2.2KW,AC380V,50HZ
Dimensions	153013501450mm	165014501450mm
Machine weight	1000kg	1200kg

Model	HYRP6-230L		HYRP8-230L
Bag types	Flat pouch, three sides sealing, four sides sealing, zipper pouch, Stand up pouch, etc
Bag material	complex film, PP, PE etc
Bag size	W:100-230mm L:150-300mm	W:100-230mm L:150-300mm
Weight range	5-1500g	5-1500g
Packing speed	30-60 bags/min Depends on material and packing amount
Air consumption	0.3m3/min
Packing accuracy	≤±1%
Power supply	2.2KW,AC380V,50HZ
Dimensions	16361240 1450mm	17651440 1450mm
Machine weight	1000kg	1200kg

Model	HYRP6-300L		HYRP8-300L
Bag types	Flat pouch, three sides sealing, four sides sealing, zipper pouch, Stand up pouch, etc
Bag material	complex film, PP, PE etc
Bag size	W:150-300mm L:150-400mm		W:150-300mm L:150-400mm
Weight range	5-1500g		5-1500g
Packing speed	20-40 bags/min Depends on material and packing amount		15-35 bags/min Depends on material and packing amount
Air consumption	0.3m3/min
Packing accuracy	≤±1%
Power supply	3KW,AC380V,50Hz;
Dimensions	17001550 1550mm	19501640 1780mm
Machine weight	1200kg	1500kg

Automatic Rotary packing machine Pictures

Automatic Given Type Rotary packing machine Work Flow

Six Position

Eight Position

Rotary given type packing machine with eight position

Automatic Given Type Rotary packing machine is suitable for below samples

Click here to view Automatic Cartoning Machine running video on YouTube

https://youtu.be/iGnsuY4H6vQ
