Box Type Model 200 Rotary Bottle Unscrambler Machine

  • MODEL: HYLP-200A
Technical description

HYLP-200A Automatic box type rotary bottle unscrambler machine is electromechanical integration equipment, convenient operation, simple maintenance and reliable running. This machine is equipped with a bottle of quantitative control detection and overload protection device. Noise is less than < 70 db. The machine plate adopt high quality stainless steel 304, in line with the GMP requirements. Using mechanical bottles of correcting mechanism, implement unified bottle. And equipped with for bottle device, greatly improving the production efficiency. This machine is equipped with three stepless speed regulating motor. One used to adjust unscramble bottle rotary speed, unscramble bottle rotary speed faster, the faster the speed of the bottle also, conversely the more slowly. And at the exit of this machine is equipped with a photoelectric switch, autonics testing bottle conveyor belt if there is a wall behind the phenomenon, such as a wall bottle, the bottle of rotary motor automatic stop. If detected lack of bottle, automatic startup. This machine realized the entire intelligent.
Suitable for: agrochemical, cosmetic, pharmaceutical, food industries such as plastic bottles automatically unscramble bottle and transportation.

Main technical data
  • Applicable bottle diameter: ф 10 mm to 65 mm by changing rotating disc plate
  • Suitable bottle type: 50-200ml plastic bottles
  • Production capacity: 50-120BPM (according to bottle spec)
  • Power supply: AC220v / 50 hz customized
  • Power: 0.5 Kw
  • Weight: 250 kg
  • Overall dimensions (length * width * height) : 1650mm * 900mm * 1200mm

Rotary bottle unscrambler machine pictures

automatic bottle unscrambler machine
automatic bottles uncrambler
automatic bottle unscrambling machine
automatic bottle sorting machine
high speed automatic bottle unscrambler

Suitable bottle sample

Suitable for round, flat, quare, all kinds of plastic bottles such as PE, HDPE, PET, PP etc bottle unscambler machine

high speed automatic bottle unscrambler machine

Click here to view rotary bottle unscrambler machine running video on youtube
